• 弹性好，抗冲击；

  Good elasticity and impact resistance;

• 定负荷伸长小，适用于长距离输送；

  Small elongation under constant load, suitable forlong-distance transportation;

• 安全性能高，能保障输送系统安全、高效运行；

  High safety performance, which can ensure the safe and efficient operation of the conveying system;

• 带体薄、重量轻、成槽性好；

  Thin belt, light weight and good grooving;

• 抗撕裂，耐屈挠性好。

Tearresistance,flexion resistance and good flexibility.

表面电阻平均值

Average surface resistance

≦3×108Ω

≦3×108Ω

滚筒摩擦性能

Drum friction performance

允许最高温≦325℃，并要求不出现有焰或无焰燃烧现象

The maximum allowable temperature is ≤ 325 ℃, and no flame or flameless combustion is required

酒精喷灯燃烧试验

Alcohol burner combustion test

平均值≦3S（带覆盖层），单值≦10S

(带覆盖层)

Average value ≤ 3S (with covering layer), single value ≤ 10s (with covering layer)

平均值≦5S (无覆盖层) ，单值≦15S

（无覆盖层）

Average value ≤ 5S (no covering layer), single

value ≤ 15s (no covering layer)

丙烷巷道燃烧性能

Combustion performance of

propane tunnel

未燃烧保留段长度＞250㎜

Length of unburned retention section ＞ 250mm

高能量巷道丙烷燃烧试验

Propane combustion test in highenergy roadway

全宽度无损坏长度＞2250㎜

Full width without damage, length ＞ 2250mm

产品规格

Product specification

拉伸强度（N/㎜）

Tensile strength (n / mm)

拉断伸长率（%）

Elongation at break (%)

撕裂力（N）≥

Tearing force (n) ≥

纵向 ≥

Longitudinal direction ≥

横向 ≥

Transverse direction ≥

纵向 ≥

Longitudinal direction ≥

横向 ≥

Transverse direction ≥

• 保持清洁避免阳光直射或雨、雪浸淋，防与酸、碱油类、有机溶剂等物质接触，并距离发热装置一米以外。存储期间成卷放置，不得折叠，放置期间应每季翻动一次。

Keep clean, avoid direct sunlight or rain and snow, prevent contact with acids, alkali oils, organic solvents and other substances, and be one meter away from the heating device. It shall be placed in rolls during storage and shall not be folded. It shall be turned once a quarter during storage.

• 储存时仓库内温度宜保持-18℃-40℃之间，相对温度宜保持在50-80%RH之间。

During storage, the temperature in the warehouse should be kept between - 18 ℃ - 40 ℃, and the relative temperature should be kept between 50-80% RH.

• 运行速度一般不宜大于2.5米/秒，块度大，磨损性大的物料和使用固定犁型卸料装置应尽量采用低速并匀速。

Generally, the running speed should not be greater than 2.5 m / s. for materials with large block and high wear and the use of fixed plow unloading device, low speed and uniform speed should be adopted as far as possible.
